Industrial Stacking Door | ABX Industrial Door Manufacturer
Industrial Stacking Door manufactured by ABX Industrial Door Manufacturer for large industrial openings. OEM branding and container-loaded export delivery available.
Product Overview
The Industrial Stacking Door stacks the door curtain above the opening, keeping the full opening width free of tracks and guides. It is the economical choice for large industrial openings where width matters more than extreme speed.
Key Features
- Clear opening up to W 12000 x H 8000 mm with virtually no width limitation
- Opening speed of 0.5-0.9 m/s for efficient vehicle flow
- Reinforced PVC with aluminum mast construction resistant to Class 5 (EN 12424) wind loads
- Rated for over 500,000 cycles with low-maintenance guides
- Soft start and soft stop protect the structure and the curtain
Technical Specifications
| Max Opening Size | W 12000 x H 8000 mm |
|---|---|
| Opening Speed | 0.5-0.9 m/s |
| Curtain | Reinforced PVC with aluminum mast |
| Wind Load | Class 5 (EN 12424) |
| Drive | Three-phase motor with frequency inverter |
Applications
Wide plant entrances, mining and heavy industry buildings with frequent large-vehicle access.
Export & Project Support
Contact hua@abxdoors.com for drawings, wind load calculations and a project-specific quotation.
